Opengear Inc. ACM7004-5 4 Cisco Straight Pinout Serial Ports USB Console Single

The Opengear Inc. ACM7004-5 is a versatile gateway/controller designed to ensure uptime and maximize WAN resilience at branch offices, retail stores, kiosks, and other remote sites. With its advanced features and capabilities, it allows for efficient management and troubleshooting of network and server devices.

Key Features:

4-8 serial ports for out-of-band management of network and server devices
4 USB console ports for out-of-band management of network and server devices
Link Layer Discovery Protocol (LLDP) for discovering, identifying, and verifying attached devices on the local network
Log audit trails to embedded 4GB local storage for troubleshooting and compliance
SmartOOB technology for secure remote access and infrastructure management
Failover to Cellular feature for uninterrupted connectivity via high-speed 3G or 4G LTE cellular networks
Strong security and authentication measures to protect network infrastructure
USB console management for easy integration with USB console-only devices

Specifications:

Ethernet LAN (RJ-45) ports: 5
Management protocols: HTTPS, SSH, Nagios NSCA, NRPE, SNMP, TFTP & FTP
DHCP server: Yes
Operating temperature: 5°C - 50°C
Operating relative humidity: 5% - 90%
Built-in processor: Yes
Interface: 4x RS-232 (RJ45), 4x USB, 2x DIO, 2x HVDO
Security algorithms: 802.1x RADIUS, FIPS 140-2, HTTPS, IPSEC, SNMP, SSH, SSH-2
Firewall security: Yes
Authentication method: RADIUS, LDAP, PAP/CHAP
Number of processors installed: 1
Processor frequency: 800 MHz
Electromagnetic compatibility: EN 55022:2010, CISPR 22:2008, FCC Part 15 Subpart B:2015, ICES-003 Issue 5 (2014), AS/NZS CISPR 22:2009 A1:2010, EN 61000-3-2:2006/A2:2009, EN 61000-3-3:2008, EN 55024:2010, CISPR 24:2010, EN 61000-4-2:2009, EN 61000-4-3:2006 A2:2010, EN 61000-4-4:2004 A1
Ethernet LAN data rates: 10,100,1000 Mbps
Data transfer rate: 1000 Mbps
Dynamic DNS (DDNS): Yes
Rack mounting: Yes
AC adapter included: Yes
Web-based management: Yes
Syslog: Yes
LED indicators: Yes
USB 2.0 ports quantity: 4
WAN connection: Ethernet (RJ-45)
Internal memory: 256 MB
Flash memory: 4032 MB
Certification: CE, UL 1950, TUV, C-Tick, RoHS
Dimensions (WxDxH): 130 mm x 120 mm x 35 mm
Weight: 600 grams
Power consumption (typical): 11.5 W
Input voltage: 110 - 240 V
Output voltage: 12 V
Cables included: AC
